Standards and Certifications
HDCP,DVI 1.0,CTS 1.2,CE,FCC,RoHS2
Generale
Cat6 cable 1080p at 50 m (165 ft.)
Cat6 cable 720p at 70 m (230 ft.)
Cat6 cable 480p at 100 m (300 ft.)
Power: 5 VDC / 1 A (cable length: 1.4 m [4.5 ft.])
Connections
Two HDMI female (transmitter)
One HDMI female (receiver)
One RJ45 female (transmitter/receiver)
One 5 VDC power female (transmitter/receiver)
One 3.5 mm IR female (transmitter/receiver)
Signal Input/Output
Input video signal: 0.5 – 1.0 V pp
Input DDC signal: 5 V pp (TTL)
Maximum single-link range: 1920x1200 at 60Hz (1080p)
Video output: HDCP 1.2, DVI 1.0
Frequency: 2.25 Gbps / 225 MHz
Video Resolutions
DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
